1. Overall Dimensions:
Size: 700mm × 450mm × 970mm
2. Main Frame:
Pillars: High-strength Φ32 × 1.2 stainless steel round tubes
Side and Back Panels: 4mm high-quality industrial aluminum-plastic boards
Handrail: Aluminum alloy handrail on the left side for easy pushing
Castors: 4 × 4-inch hollow wheels with ABS anti-winding covers; 2 with brakes
3. Top Structure:
Work Surface:
Material: ABS high-grade engineering plastic, one-time injection molding
Design: Three-sided ABS fence, smooth and aesthetically pleasing
IV Pole:
Adjustable height, made of Φ16 stainless steel tube
First aid tray: Acrylic board with 4 straps, 360° rotation
4. Middle Structure:
Drawers:
Specifications:
5 drawers: 3 small, 1 medium, 1 large
Removable plastic baskets:
Large: 400 × 600 × 200mm
Medium: 400 × 600 × 100mm
Small: 400 × 600 × 50mm
Each basket capacity: ≥60kg
Drawers can be combined as needed
Sliding Rails:
High-quality three-section mute rails, 60cm extension, self-locking function
Internal Configuration:
ABS movable dividers for flexible compartmentalization
Standard identification cards for clear labeling
Front Panel and Frame:
Steel structure with ABS arc-shaped handles
Side Extraction Plate:
Located on the right side for convenient item storage
5. Bottom Structure:
Base: Material: ABS high-grade engineering plastic, one-time injection molding
6. Additional Features:
Transparent ABS file box
CPR board
Oxygen tank holder
Power outlet
Needle disposal container
2 plastic flip-top waste bins
