About this product
- Materials: Steel
- Size: 3245*1430*2270mm
- Color: Yellow
- Power source: Other
- Load capacity: 1-10t
- Tire certification: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: Steel
- Size: 3245*1430*2270mm
- Color: Yellow
- Power source: Other
- Load capacity: 1-10t
- Tire certification: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | Steel |
|---|---|
| Size | 3245*1430*2270mm |
| Color | Yellow |
| Power source | Other |
| Load capacity | 1-10t |
| Tire certification | Other |
| Engine capacity | Other |
| Drive wheel | Other |
| Horsepower | Other |
Product details
| Materials | Steel |
|---|---|
| Size | 3245*1430*2270mm |
| Color | Yellow |
| Power source | Other |
| Load capacity | 1-10t |
| Tire certification | Other |
| Engine capacity | Other |
| Drive wheel | Other |
| Horsepower | Other |
From the supplier
Safety
Overhead Safeguard
Robust Overhead Safeguard and its supporting frame form safe area to avoid the accident and protect the operator.
Throttling Valve
A throttling valve is set in the piping system.The mast won’t result in failing control of mast even some pipe are cracked.
Wide View Mast
The wide view mast design guarantee the operator have good visibility,avoid the accident.
Low Gravity
The low gravity design make the forklift safer when steering.
Seat With Safe Belt
The forklifts are equipped with high quality seat with safe belt,keep the operator on a safe position
Performance
Specially designed drive train combination guarantee the forklift work with stable power output under low fuel consumption and low emission level,combining the unique control system and reasonable design,it enable the operator to use the forklift easily and maximize productivity.
Comfort
Focusing on the ergonomic design concept,a perfect operating experience is available.
Low entry foot-pedal and an assistance grip on the safe guard,it’s easy for step into the forklift and leave it.The spacious cab,adjustable seat and steering column can meet different operating habit and allow fast and stress-free working.
Maintenance & Servicing
The engine cover have almost 90 degree opening range and one-touch removal of the floorboard leave the technician with an easy access; Clear and reasonable layout in the engine cabin give the technician a clear mind of the whole structure.
1
Model
FD50
2
Power Type
Diesel
3
Rated Capacity
kg
5000
4
Load Centre
mm
500
5
Lift Height
mm
3000
6
Fork Size
L*W*T
mm
1070x150x55
7
Mast Tilt Angle
F/R
Deg
6°/12°
8
Front Overhang(Wheel centre to fork face)
mm
579
9
Overall Dimension
Length to face of fork (without fork)
mm
3260
10
Overall Width
mm
1460
11
Mast Lowered Height
mm
2270
12
Overhead Guard Height
mm
2340
13
Turning Radius (outside)
mm
2910
14
Min.insecting aisle
mm
2920
15
Speed
Travel (Empty load)
km/h
20
16
Lifting (Full load)
mm/s
380
17
Max.Gradeability
%
20
18
Tyre
Front
300-15-18PR
19
Rear
7.00-12-12PR
20
Wheelbase
mm
2100
21
Service weight
kg
6700
22
Battery
Voltage/Capacity
V/Ah
2x12/80
23
Engine
Model
4DX23
24
Manufacture
XiChai
25
Rated output/r.p.m
Kw
60/2200
26
Rated torque/r.p.m
N·m
320/1400-1700
27
No.of Cylinder
4
28
Bore x Stroke
Mm
102×118
29
Displacement
cc
3857
30
Transmission
Type
Hydraulic
31
Stage (FWD/RVS)
2/2
32
Operating Pressure for Attachment
Mpa
18
From the supplier
Safety
Overhead Safeguard
Robust Overhead Safeguard and its supporting frame form safe area to avoid the accident and protect the operator.
Throttling Valve
A throttling valve is set in the piping system.The mast won’t result in failing control of mast even some pipe are cracked.
Wide View Mast
The wide view mast design guarantee the operator have good visibility,avoid the accident.
Low Gravity
The low gravity design make the forklift safer when steering.
Seat With Safe Belt
The forklifts are equipped with high quality seat with safe belt,keep the operator on a safe position
Performance
Specially designed drive train combination guarantee the forklift work with stable power output under low fuel consumption and low emission level,combining the unique control system and reasonable design,it enable the operator to use the forklift easily and maximize productivity.
Comfort
Focusing on the ergonomic design concept,a perfect operating experience is available.
Low entry foot-pedal and an assistance grip on the safe guard,it’s easy for step into the forklift and leave it.The spacious cab,adjustable seat and steering column can meet different operating habit and allow fast and stress-free working.
Maintenance & Servicing
The engine cover have almost 90 degree opening range and one-touch removal of the floorboard leave the technician with an easy access; Clear and reasonable layout in the engine cabin give the technician a clear mind of the whole structure.
1
Model
FD50
2
Power Type
Diesel
3
Rated Capacity
kg
5000
4
Load Centre
mm
500
5
Lift Height
mm
3000
6
Fork Size
L*W*T
mm
1070x150x55
7
Mast Tilt Angle
F/R
Deg
6°/12°
8
Front Overhang(Wheel centre to fork face)
mm
579
9
Overall Dimension
Length to face of fork (without fork)
mm
3260
10
Overall Width
mm
1460
11
Mast Lowered Height
mm
2270
12
Overhead Guard Height
mm
2340
13
Turning Radius (outside)
mm
2910
14
Min.insecting aisle
mm
2920
15
Speed
Travel (Empty load)
km/h
20
16
Lifting (Full load)
mm/s
380
17
Max.Gradeability
%
20
18
Tyre
Front
300-15-18PR
19
Rear
7.00-12-12PR
20
Wheelbase
mm
2100
21
Service weight
kg
6700
22
Battery
Voltage/Capacity
V/Ah
2x12/80
23
Engine
Model
4DX23
24
Manufacture
XiChai
25
Rated output/r.p.m
Kw
60/2200
26
Rated torque/r.p.m
N·m
320/1400-1700
27
No.of Cylinder
4
28
Bore x Stroke
Mm
102×118
29
Displacement
cc
3857
30
Transmission
Type
Hydraulic
31
Stage (FWD/RVS)
2/2
32
Operating Pressure for Attachment
Mpa
18
