MAF4-400 The feeder 3 in 1 for middle-thickness material

-The feeder 3 in 1 is a comprehensive device equipped with uncoiler, straightener and feeder three parts. It is designed with the advantages of less space occupying and higher feeding accuracy.

-The specially made automatic towing system for thick and the wider material, which reduced the human labor, improved work efficiency and avoided the danger in material towig.

-Material pressed arm holds the material tightened. While the uncoiler moves, the motor in the arm runs in opposite direction and faster, which gurantees the material hold tightly.

-The hydraulic expansion of the uncoiler brings great convenience to the loading of material. The disk braking system improves the stability of uncoiler while stopping and protected the speed reducer and motor.

-The straightener and feeder are designed on the same frame, powered by the same servo-motor, so the strip will be clamped more tighten and less sliding while feeding, the feeding accuracy and stability achieved. The height of the frame can be adjusted in case of the different height of the die.

-Optional: coil loading trolley, convenient of coil loading and safe operation; hydraulic scissors, used for cutting the deformed material head and tail; open-able leveling unit, brings convenience for the cleaning of leveling rollers, suitable for products with high surface requirements; feeder for the end of coil, suitable for H type press, because of the feeder is far from mold, the feeder designed for the feeding of the end of coil about 2m, to improve the material utilization rate.

Product Parameters

item unit diameter note Material width mm 50-400 Material thickness mm 0.5-4.5 Material weight Kg 3000 I.D. of coil mm Φ480-520 O.D. of coil mm Φ1050-1600 Straightening rollers umber 10rollers.up5/down5, Φ68MM Feeding rollers number 2rollers.up1/down1, Φ84MM Feeding accuracy mm 0-1000±0.2 Air source Mpa 0.55-0.5 Servo motor kw AC2.9 Decoiler motor kw AC1.5 Feeding height mm Customer requirement 1200 ±100 to be filled by buyer Range of I.D. mm Φ480-Φ520 Way of expansion Hydraulic expansion Feeding direction Customer requirement to be filled by buyer Suitable material cold-reduced sheet, hot rolled sheet, pickling sheet, stainless steel and cooper Power source AC380±10%,50HZ,three phases or customized as per local voltage Notice the voltage Machine color white(body9010)moving part(yellow)

Configure the main parameters

item name brand note 1 motor Wanshsin 2 Servo motor Yaskawa 3 Human-machine interface MGCS/WEINVIEW 4 PLC Mitsubishi 5 breaker Schneiders 6 contactor Schneiders 7 button Schneiders 8 Relay IDEC 9 Pneumatic components Airtac 10 Hydraulic components Chuanglibo 11 Photoelectric induction Autonics 12 cylinder Airtac 13 Straightening bearings NSK 14 Frequency shifter Delta/Mitsubishi 15 Servo motor driver Yaskawa

FAQs

Q1: Who are you?
We are Hunan Qinfeng Robot Corporation Limited

Q2: Are you a factory or trading company?
We are a factory.

03: What service do you provide and what are your products?
We provide one-stop solution to stamping automation. Except punch press, wemake all equipment including stamping manipulators, stamping robots, 3 in 1decoiler straightener feeder, destacker,3D transfer manipulator,independenttransfer manipulator, one bar transfer manipulator, progressive die, singlemold and stamped products in our own factory.

Q4: Where is your factory located? How can l visit your factory?
We are located in Huarong, Yueyang, Hunan. You can take high speed train toYueyang station or fly to Yueyang airport. We can pick you up from Yueyangstation or airport. lt's about 1 hour by car from our factory to Yueyang stationor airport.

05:ls your machinery standard or customized?
Both. Most machinery are standard models. lf standard models can't meet yourpersonal needs,we can customize as per your personal needs.

06: How does your factory's quality system work?
QUALITY IS PRIORITY. We check all machines parts before installation and allmachines will be tested before shipment.

07: How long is the warranty of the machine?
The warranty is one year. With good maintenance, the machines can be used
more than 10 years.

Q8: Do you have after sales service?
Yes, we have some overseas service partners that can provide on-siteafter-sales service.In those countries we haven't had service team, we arehappy to provide support through mail, visual phone and etc.

09:ls it possible to be a foreign agent and distributor?
Yes. Welcome to be our agent or distributor if you have sales and after-salesservice team in the stampingindustry.
