2.5ton all-terrain forklift

2.5ton all-terrain forklift ,Standard configuration:

1.Standard 2-stages 3m mast,Japan Yanmar

2.Forks,water-thermometer,Traction Pin,Load - backrest,overhead guard,electric hom,reversing light,Chronoscope,fuel gauge,Charging indication,tool box,free spare parts,Oil pressure alam,tum light indicator,High visibility mast,seat with arm and safety Belt,Headlamp,combination rear lamp,Formedpedal pad,Multiple unit valve,transmission oil filter,Back-up Buzze,Transmission oil scale,hydraulic circuit oil filter,Neutral safety switch,overhead guard appentice,air intake installation,Durable tyre,Cable type parking brake,Hydraulic oil scale,Preheat indicator,Hydraulic power transmission,Lifting jack govemor valve,Lifting and tilting joy stick,

whirlwind joy air filter,Automatic engine preheating system,etc.

Alternative equipment:

Mast type:Standard 2-stages,full free 2-stages/duplex mast,full free 3-stages/triplex mast.

Mast height:3m,3.5m,4m,4.5m,4.8m,5m,5.5m,6m,6.5m,7m,etc.

Engine:Isuzu, Yangma, Mitsubishi, etc.

Tire: solid tire, Non-marking solid tire

Seats: Toyota seats, suspension seats, OPS seats

Alternative equipment：

Cabin,speed indicator,fire extinguisher,solid tyre,rear work light,Auxiliary Piping,floated seat,Specify Colors,transmission oil ,temperature gauge,fan heater,High exhaust device,etc.

Alternative attachment:

Side shifter,Fork Positioner,Paper Roll Clamp,Push / Pull,Carton Clamp,Rotator,Carpet Boom,Tipping Mult-purpose Clamp,Drum Clamp,Tumaload,Tumafork,Single Double Pallet Handlers,Double Wide Sideshifters,forks,Glass Handler,etc.

Product Description2500kg all-terrain forklift  with standard 2-stage 3m mast and Japan Yanmar engine

2.5ton all-terrain forklift Standard 2-stages 3m mast

1.Automatic transmission

2.1070mm  fork length

3.On/off on key switch

4.Toyota Seat with belt,with reversing buzzer

5.Pneumatic tire

6.Tool box,warning light and full sets of LED lights.     7.Including all other standard configures
Product Paramenters



Specification1Model　FD25T-C22Power 　Diesel 3Type　　4Loading capacityKg25005Loading center mm500Size 6Lifting heightmm30007Free Lifting heightmm1608Fork sizeL×W×Tmm1070x122x409Adgust size Mini/maxmm250-116010AngleFront/rearDeg10°/12°11Front overhangmm58612Rear overhangmm52013Minimum ground clearancemm27014SizeLength (without fork)mm294615widthmm1557.516Mast when lowed mm226517Mast lifting height with  Load-backrestmm417518Distance from seat to overhead guardmm2256.519Turning radiusmm287020Min. Intersecting aislemm4726Performance21Speeds
Max.Drive speeds(with/without load)Km/h20/1822Lifting speeds (with load)mm/s57023Lowering speeds(with /without full load)mm/s60024 Max. tractive forceKN1725Max.grade ability (with/without full load)％20
Product packagingStandard export packing, triangular wood, strapping, foam bags.

20'' container:3sets 2.5ton diesel forklift

40'' container:5sets 2.5ton diesel forkliftOur factoryGate

Reception area

Office

Workshop

Certificate

BV

CE

SGS

ISO

Our team

Exhibision

In india Exhibition

Poland Exhibition

South Africa Exhibition

China Canton Fair

Our forklifts advantages

Safety

Intelligent starting system , forklift hanging gear start prevent function , it improves the operation safety and longer gearbox service life.

Hydraulic power brake system , large capacity accumulator , reliabledriving and emergency brakinge.

Overhead guard with high-strength steel plate one stamping , pro -vide driver more sophisticated security.

Standard equipped button parking brake , effectively prevent the hand brake from accidentally release.



Comfort

Ergonomic design, rational operating device layout, equipped with adiustable seat (adjustment up to 150 mm )and steering wheel.

All forklift models standard with hydraulic steering system, easy and comfort to operate.



Advancement

Word famous imported diesel and gasoline engine, Japan TCM gearbox for options,intelligent LCD instrument, CAN, Controller Area Network, real-timedisplay of engine and forklift’s Working information



Reliability

Cooling system meet the requirements of the China standard. Theinter-cooling, scattered water, oil scattered are independent lay-out, which gratly increase the engine, gearbox and other core components quality.Hydraulic system gives large-capacity oil absorption and oil returnfilter to ensure efficient work.Engine standard with two-stage filter design(cyclone type filter+air dry filter).



Reliable steering system

The steering system adopying new technology not only ensure steady steering, quick positioningand steering, but also ensure the driver' s safety.



A reliable mast

Emphasis on the inherent quality of the mast has provided operator a reliable security . Wide view mast makes vision more clearly.We adopted the mast channel which has the world-class quality .The corss-section of mast channel has been in -creased and the structure become more strong.



New drive and control system

Adop the international electric actuators and makes the truck steering more stable , and output power stronger .New electronic blanker improves the comfort and safety of the operation



High performance hydraulic system

Load sensing priority steering hydraulic system design , flexible steering , mast lift speed increased by 20%.

Tilt cylinder, lifting cylinder and steering cylinder are equipped with oil seal as standard; lifting cylinder is equipped with lowering buffer function as standard.



Comfortable driving space

All accessories like engine , gear boxare support by domestic and worldfamous brand , high quality , reliable after-sales.
