1bzx Hydraulic Pressure Offset Heavy Disc Harrow
SHANDONG YUNTAI MACHINERY CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
1bzx Hydraulic Pressure Offset Heavy Disc Harrow
SHANDONG YUNTAI MACHINERY CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: Q235 Steel ,65Mn Steel
- Color: Product color according to customer requirements
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
About this product
- Materials: Q235 Steel ,65Mn Steel
- Color: Product color according to customer requirements
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
Product details
| Materials | Q235 Steel ,65Mn Steel |
|---|---|
| Color | Product color according to customer requirements |
Product details
| Materials | Q235 Steel ,65Mn Steel |
|---|---|
| Color | Product color according to customer requirements |
From the supplier
This harrow has high harrowing capacity with reasonable utilization of power, great ability to cut and shatter the soil, level soil surface and loosen soil after harrowing, being well adaptable for heavy clay soil wasteland and weedy fields as well. This harrow has been adopted combined structure whose rigid frame is welded with rectangular tube, equipped with hydraulic up and down road wheel spring leveling device and tapered roller bearings and square/round inner hole special for disc harrow. Therefore this machine is easy to move with small turning radius simple to be adjusted and maintained.
Parameter:
Model
1BZX-2.0
1BZX-2.2
1BZX-2.35
1BZX-2.5
1BZX-3.0
1BZX-3.5
Number of disc
18
20
22
24
28
32
Diameter of disc(mm)
660*6
Working width(mm)
2000
2200
2350
2500
3000
3500
Weight (kg)
1740
2050
2150
2250
2450
2950
Tractor(hp)
85-95
95-100
100-130
130-160
140-180
180-250
Disc spacing
9"(230mm)
Axle size
Square or round 1.4/7"(40mm)
Depth cut
7"-8.5/8"(180-220mm)
Bearing Assembly
Grease or oil bath
