Application

It can be laid indoors, outdoors, in tunnels, cable trenches, reinforced concrete pipes and loose soil. The cables shall not bear external forces, but can bear certain traction.

Product Performance

(1)The long-time permissible operation temperture of conductor shall not be higher than 70oC.
(2)Conductor maximum short circuit(not more than 5 seconds)temperature shall not be higher than 160 oC.
(3)The power cable is not limited by drop in level when being laid,and the ambient temperature shall not be lower than 0 oC.
(4)Perfect chemical stability,resistant against acids,alkalis,grease and organic solvents,and flame.
(5)Light weight,perfect bending properties,installed and maintained easily and conveniently.
Voltage rating:0.6/1kV3.6/6kV.
Conductors:copper or aluminum.
Number of cable cores:one core(Single core),two cores(Double cores),three cores,four cores(Four Equal-section-area cores or three equal-section-area cores and one smaller section area neutral core),five cores(Five equal-area cores or three equal-section-area cores and two smaller section area neutral cores).We provide armoured trpe and non-armored type for the power cables above.
Our company has been carrying out Chinese national standard GB 12706 and GB 12666.6(equivalent to IEC 60502 and IEC 60331)for PVC insulated power cable and fire resistant cable needed by domestic customer,and for foreign customers we can manufacture in accordance with BS,DIN and other countries,standards.In addition,we can design and manufacture PVC insulated power cable with special characteristics according to needs of customers.

Cu Core

AL Core

Description

VV

VH-VV

VLV

NH-VLV

Cu(Al)Core PVC Insulated PVC Sheathed Power Cable

Cu(Al)Core PVC Insulated PVC Sheathed Fire Resistant Cable

VY

NH-VY

VLY

NH-VLY

Cu(Al)Core PVC Insulated PE Sheathed Power Cable

Cu(Al)Core PVC Insulated PE Sheathed Fire Resistant Cable

VV22

NH-VV22

VLV22

NH-VLV22

Cu(Al)Core PVC Insulated Steel Tape Armored PVC Sheathed Power Cable

Cu(Al)Core PVC Insulated Steel Tape Armored PVC Sheathed Fire Resistant Cable

VV23

NH-VV23

VLV23

NH-VLV23

Cu(Al)Core PVC Insulated Steel Tape Armored PE Sheathed Power Cable

Cu(Al)Core PVC Insulated Steel Tape Armored PE Sheathed Fire Resistant Cable

VV32

NH-VV32

VLV32

NH-VLV32

Cu(Al)Core PVC Insulated Fire Steel Wire Armored PE Sheathed Power Cable

Cu(Al)Core PVC Insulated Fire Steel Wire Armored PE Sheathed Fire Resistant Cable

VV33

NH-VV33

VLV33

NH-VLV33

Cu(Al)Core PVC Insulated Fire Steel Wire Armored PE Sheathed Power Cable

Cu(Al)Core PVC Insulated Fire Steel Wire Armored PE Sheathed Fire Resistant Cable

VV42

VH-VV42

VLV42

NH-VLV42

Cu(Al)Core PVC Insulated Thick Steel Wire Armored PVC Sheathed Power Cable

Cu(Al)Core PVC Insulated Thick Steel Wire Armored PVC Sheathed Fire Resistant Cable

VV43

VH-VV43

VLV43

NH-VLV43

Cu(Al)Core PVC Insulated Thick Steel Wire Armored PE Sheathed Power Cable

Cu(Al)Core PVC Insulated Thick Steel Wire Armored PE Sheathed Fire Resistant Cable

Nominal Cross-Section AreaofConductor Core

Master Core

2.5

4

6

10

16

25

35

50

70

95

120

150

185

3+1Neutral Core

1.5

2.5

4

6

10

16

16

25

35

50

70

70

95

3+2Neutral Core

1.5

2.5

4

6

10

16

16

25

35

50

70

70

95

4+1Neutral Core

1.5

2.5

4

6

10

16

16

25

35

50

70

70

95

Nominal Thickness of Insulation

Cross Section(mm2)/KV

1

1.5

2.5

4

6

10

16

25

35

50

70

95

120

150

185

0.6/1

0.8

0.8

0.8

1

1

1

1

1.2

1.2

1.4

1.4

1.6

1.6

1.8

2.0

3.6/6

-

-

-

-

-

3.4

3.4

3.4

3.4

3.4

3.4

3.4

3.4

3.4

3.4

DC Resistance of Insulation(mm)

Nominal section Area

(mm2)

Resistance not More than

(Ω/km)

Nominal section Area

(mm2)

Resistance not More than

(Ω/km)

Resistance not More than

(Ω/km)

Nominal section Area

(mm2)

Resistance not More than

(Ω/km)

Cu

Al

Cu

Al

Cu

Al

Cu

Al

1.5

12.1

18.1

25

0.727

1.20

0.124

0.206

630

0.0283

0.0469

2.5

7.41

12.1

35

0.524

0.868

0.0991

0.164

800

0.0221

0.0369

4

4.61

7.41

50

0.387

0.641

0.0754

0.125

1000

0.0176

0.0291

6

3.08

4.61

70

0.268

0.443

0.0601

0.100

-

-

-

10

1.83

3.08

90

0.193

0.320

0.0470

0.0778

-

-

-

16

1.15

1.91

120

0.153

0.253

0.0366

0.0605

-

-

-
