0.6/1KV XLPE Insulation PVC Sheath Low Voltage Power Cable
Guda Wire and Cable (group) Co., Ltd.
See what’s includedHide breakdown
- FOB goods (500)
- $38,700
- Ocean freight + handling (1.5 CBM)
- $880
- US duty (2.7%)
- $1,045
- Section 301 tariff (25.0%)
- $9,675
- Customs fees (MPF/HMF)
- $182
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (500)
- $38,700
- Ocean freight + handling (1.5 CBM)
- $880
- US duty (2.7%)
- $1,045
- Section 301 tariff (25.0%)
- $9,675
- Customs fees (MPF/HMF)
- $182
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
0.6/1KV XLPE Insulation PVC Sheath Low Voltage Power Cable
Guda Wire and Cable (group) Co., Ltd.See what’s includedHide breakdown
- FOB goods (500)
- $38,700
- Ocean freight + handling (1.5 CBM)
- $880
- US duty (2.7%)
- $1,045
- Section 301 tariff (25.0%)
- $9,675
- Customs fees (MPF/HMF)
- $182
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (500)
- $38,700
- Ocean freight + handling (1.5 CBM)
- $880
- US duty (2.7%)
- $1,045
- Section 301 tariff (25.0%)
- $9,675
- Customs fees (MPF/HMF)
- $182
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 1*1.5-5*630
- Color: Black
- Application: Other
- Rangeof application: Other
- Insulation material: XLPE
- Brand: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China
About this product
- Size: 1*1.5-5*630
- Color: Black
- Application: Other
- Rangeof application: Other
- Insulation material: XLPE
- Brand: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China
Product details
| Size | 1*1.5-5*630 |
|---|---|
| Color | Black |
| Application | Other |
| Rangeof application | Other |
| Insulation material | XLPE |
| Brand | Other |
| Conductor material | Other |
| Sheath material | PVC |
| Conductor type | Other |
| Material shape | RoundWire |
| Certification | CCCISO9001 |
Product details
| Size | 1*1.5-5*630 |
|---|---|
| Color | Black |
| Application | Other |
| Rangeof application | Other |
| Insulation material | XLPE |
| Brand | Other |
| Conductor material | Other |
| Sheath material | PVC |
| Conductor type | Other |
| Material shape | RoundWire |
| Certification | CCCISO9001 |
From the supplier
Low voltage power cable is a type of cable used to transmit low-voltage electrical energy, widely used in power supply and transmission systems in residential, commercial buildings, industrial equipment, public facilities, and other places.
Product Application
Used for fixed installation in distribution networks or industrial devices with a rated power frequency voltage of 0.6/1KV or below.
Characteristics
1.The allowable long-term maximum working temperature of cable conductors: PVC insulated cables: 70 ℃, XLPE insulated cables: 90 ℃.
2. When the cable is short circuited (maximum duration of 5 seconds), the maximum temperature of the conductor shall not exceed: PVC insulated cable, sectional area ≤ 300mm² 160 ℃, PVC insulated cable, sectional area ＞300m² 140 ℃; XLPE insulated cable 250 ℃.
3. The ambient temperature during laying should not be lower than 0 ℃.
4.The allowable bending radius of the cable is:
Single core cable: armored type, the bending radius is ≥ 15D during installation, non-armored type, it is ≥ 20D;
Multi-core cable: armored type, the bending radius is ≥ 12D during installation, non-armored type, it is ≥ 15D;
D is the outer diameter of the cable.
From the supplier
Low voltage power cable is a type of cable used to transmit low-voltage electrical energy, widely used in power supply and transmission systems in residential, commercial buildings, industrial equipment, public facilities, and other places.
Product Application
Used for fixed installation in distribution networks or industrial devices with a rated power frequency voltage of 0.6/1KV or below.
Characteristics
1.The allowable long-term maximum working temperature of cable conductors: PVC insulated cables: 70 ℃, XLPE insulated cables: 90 ℃.
2. When the cable is short circuited (maximum duration of 5 seconds), the maximum temperature of the conductor shall not exceed: PVC insulated cable, sectional area ≤ 300mm² 160 ℃, PVC insulated cable, sectional area ＞300m² 140 ℃; XLPE insulated cable 250 ℃.
3. The ambient temperature during laying should not be lower than 0 ℃.
4.The allowable bending radius of the cable is:
Single core cable: armored type, the bending radius is ≥ 15D during installation, non-armored type, it is ≥ 20D;
Multi-core cable: armored type, the bending radius is ≥ 12D during installation, non-armored type, it is ≥ 15D;
D is the outer diameter of the cable.
About the supplier
- ✓Exhibited at 3 recent Canton Fairs
- ✓Industry and Trade Company
- ✓Founded 2011
- ✓Canton Fair Premium Supplier
Light & Electrical exhibitors show in Phase 1 of the Canton Fair, 15 to 19 October 2026.
- Exhibited at 3 recent Canton Fairs
- Industry and Trade Company
- Founded 2011
- Canton Fair Premium Supplier
